Road Cutter ER555F-s
-
Road Cutter ER555F-s
Feature
A 28T, fast mobilization speed milling machine. It makes milling jobs profitable, especially jobs on city roads with manholes, curbs, etc. and frequent short distance hauls.
- Driving speed: Max 27 km/h
- Side-shifted up to 450 mm, providing versatility on roads where there is a lot of obstruction.
- Designed based on the bogie system which reduces any disturbance to the cutter drum during operation
- High maneuverability allows the ER555F-s to move between jobsites without the need for transport, saving both time and cost.
- Conveyor folds over the top for easy loading and unloading onto flatbeds. ER555F-s’s low transport weight means it can be transported via smaller transports.
Specification
MODEL | ER555F-s | |
---|---|---|
WEIGHTS | ||
Max. operating weight | kg (lbs) | 27,875 (61,455) |
Operating weight | kg (lbs) | 26,620 (58,685) |
DIMENSIONS | ||
Overall length | mm (in) | 10,265 (404) |
Overall width | mm (in) | 2,460 (97) |
Overall height(operate) | mm (in) | 3,180 (125) |
Overall height(Shipping) | mm (in) | 2,915 (112) |
Wheelbase | mm (in) | 6,000 (236) |
ENGINE | ||
Make | KOMATSU | |
Model | SAA6D140E-5 | |
Type | Diesel, EPA-Tier2,Stage-Ⅱ: equivalent |
